Datalogic Magellan™ 9600i In-Counter Scanner – Medium Platter, Fixed Produce Rail, ScaleSentry, Flange Mount, USB, AI-Ready

Non-rugged, Wired, Datalogic, Presentation, 2D, USB, Midrange, Grey, General purpose, Mid Level, Retail, 1 Year, New
[Contact us for a price] Request a quote
For Special & Volume Pricing - Call +441749608334
96112001000-003520

Need Help

Choosing a Product
+441749608334 Live Chat Email Us
Talk to our technical Expert
price match

Description

Optimised for UK retail environments, the Datalogic Magellan™ 9600i Scanner Only offers industry-leading imaging performance with a medium All-Weighs™ platter, fixed produce rail, and flange mount design—perfect for assisted or self-checkout lanes.

Powered by the next-gen QuadVision™ technology, the 9600i features 4 high-resolution cameras (2 vertical, 2 horizontal) combined with a multi-core IMX8 processor, enabling 5-sided scanning and lightning-fast decoding—even on damaged or poorly printed barcodes.

This scanner includes ScaleSentry™ infrared detection, which alerts cashiers to items placed outside the weighing area, ensuring accurate measurements and preventing shrink at checkout. The AI-ready architecture supports optional neural processors, Coral TPU, and dual colour cameras for future upgrades like produce recognition and video analytics.

Designed with smooth surfaces and capacitive touch controls for hygienic, high-throughput environments, the 9600i integrates seamlessly with existing POS systems via USB Type A and includes a US-standard power brick and cord for universal deployment.

Whether in grocery, retail, or hospitality sectors, this unit delivers unmatched reliability, scalability, and intelligence at the point of sale.

Product Features

  • QuadVision™ Imaging Engine: 4-camera, 5-sided barcode scanning for unmatched accuracy
  • IMX8 Multi-Core Processor: Fast decoding of all 1D/2D and GS1 Digital Link barcodes
  • ScaleSentry™ Infrared Detection: Alerts cashiers to under-weighed items caused by misplacement
  • Fixed Produce Rail: Securely handle fruits and vegetables at checkout
  • Medium All-Weighs™ Platter: Weigh oversized items using bonnet surface
  • AI-Ready Design: Optional Coral TPU, dual colour cameras, and neural processors
  • Capacitive Touch Controls: Modern interface with easy-clean surfaces
  • Flange Mount Installation: Secure in-counter fit for long-term use
  • Multi-Interface Support: USB Type A with Power, RS-232, IBM 46XX, Ethernet options
  • Retail-Optimised: Ideal for supermarkets, convenience, and self-service setups


Product Specifications

Attribute

Details

Brand

Datalogic

Model

Magellan™ 9600i Scanner Only – Medium, Fixed Rail

Platter Size

Medium All-Weighs™

Produce Rail Type

Fixed

Mount Type

Flange Mount

Scan Engine

QuadVision™ – 4-Camera 2D Area Imager

Processor

IMX8 Multi-Core, Embedded Linux OS

Power Requirements

12VDC (9.3W Operational, 7.3W Sleep)

OS Compatibility

Windows, Linux, Android, IBM 4690

Audio Feedback

85 dB speaker, tone/volume adjustable, WAV support

ESD Protection

Up to 25kV air discharge

Environmental Rating

Operating: 10°C–40°C, Storage: -40°C–70°C

Humidity Tolerance

5–95% RH (non-condensing)

AI Upgradeability

Yes – Supports Coral TPU, neural processors

Warranty

1-Year Factory Warranty

Features

Connectivity:
  • Wired
Ruggedness:
  • Non-rugged
Brand:
Datalogic
Form Factor:
  • Presentation
Scan Engine/Technology:
  • 2D
Interface:
  • USB
Scan Range:
  • Midrange
Colour:
  • Grey
Rugged:
  • General purpose
Usage:
  • Mid Level
Industry/Vertical:
  • Retail
Warranty:
  • 1 Year
Product Type/Condition:
  • New

Attachments

Brochure (4136-datasheet.pdf, 167 Kb) [Download]
