Datalogic PowerScan PM9600-HP High Performance 910 MHz Wireless Barcode Scanner Kit – USB (Non-EU Version)

Wireless, Rugged, Datalogic, Handheld, 2D, USB, Standard Range, Yellow, Rugged/Heavy Duty, Industrial, IP67, Logistics/Warehouse, 3 Years, New
[Contact us for a price] Request a quote
For Special & Volume Pricing - Call +44 174 960 8334
PM9600-HP910RBK10

Need Help

Choosing a Product
+44 174 960 8334 Live Chat Email Us
Talk to our technical Expert
price match

Description

The Datalogic PowerScan PM9600-HP USB Kit delivers superior performance and rugged reliability for high-volume industrial barcode scanning. Featuring 910 MHz STAR Cordless System™ wireless connectivity, this non-EU model provides extended radio range and dependable communication in manufacturing, logistics, and warehouse environments.

This kit includes the PowerScan PM9600-HP scanner, a BC9630-910 cradle with USB interface, CAB-552 USB cable, and a power supply set. The PM9600 series stands out with inductive wireless charging, eliminating exposed contact points and significantly reducing maintenance costs. The high-performance scan engine captures low-contrast, damaged, and high-density 1D and 2D barcodes with speed and accuracy, even in poor lighting.

Designed for extreme industrial conditions, the scanner boasts IP67 protection, withstands 2.5 m drops, and operates in temperatures as low as -20°C. The ergonomic grip and intelligent Motionix™ technology ensure seamless transition between handheld and hands-free use for UK operators who demand precision and productivity.

Product Features

  • High Performance scanning of 1D/2D/Digimarc® codes with wide depth of field
  • 910 MHz Datalogic STAR Cordless System™ with up to 230 m range
  • Wireless charging cradle eliminates contact wear and tear
  • USB interface via cradle (CAB-552 cable included)
  • Ultra-rugged design: IP67 scanner and IP65 cradle, 2.5 m drop-rated
  • Up to 80,000 reads per charge with 3350 mAh Li-ion battery
  • Datalogic 3GL™ and Green Spot technology for visual read confirmation
  • Motionix™ motion-sensing enables automatic mode switching
  • Loud adjustable beeper and vibration feedback
  • Non-EU radio compliance version, ideal for UK and international use


Product Specifications

Specification

Details

Model

PM9600-HP (High Performance)

Wireless Technology

Datalogic STAR Cordless System™, 910 MHz

Radio Range (Open Air)

Up to 230 m low speed, 180 m high speed

Battery

3350 mAh removable Li-ion, up to 80,000 reads per charge

Charging Method

Inductive wireless charging

Connectivity

USB via cradle (Multi-interface cradle BC9630-910)

Scan Engine

High Performance 1D/2D Imager

Resolution

1D: 2.5 mil, 2D: 4 mil

Drop Resistance

2.5 m @ 20°C, 2.0 m @ -20°C

Sealing

IP67 (Scanner), IP65 (Cradle)

Ambient Light Tolerance

0 – 100,000 lux

Weight

425 g

Dimensions (H x L x W)

19.8 x 14.0 x 7.9 cm

Temperature Range

-20°C to 50°C (operating), -40°C to 70°C (storage)

Indicator Feedback

3GL™, Green Spot, LEDs, Beeper, Vibration

Software Utilities

Datalogic Aladdin™, OPOS, JavaPOS

Compliance

China RoHS, EU RoHS, REACH

Warranty

3-Year Factory Warranty



Features

Connectivity:
  • Wireless
Ruggedness:
  • Rugged
Brand:
Datalogic
Form Factor:
  • Handheld
Scan Engine/Technology:
  • 2D
Interface:
  • USB
Scan Range:
  • Standard Range
Colour:
  • Yellow
Rugged:
  • Rugged/Heavy Duty
Usage:
  • Industrial
IP Rating:
  • IP67
Industry/Vertical:
  • Logistics/Warehouse
Warranty:
  • 3 Years
Product Type/Condition:
  • New

Attachments

Brochure (4000-datasheet.pdf, 280 Kb) [Download]
