Description
The Honeywell HF811 Fixed Industrial Scanner with 2MP resolution, narrow field of view, and red LED illumination is designed for robust barcode scanning performance in high-speed manufacturing and package handling environments. Its compact size, powerful decode algorithms, and rugged IP65 housing make it ideal for integration into space-constrained automation systems.
With support for Direct Part Marking (DPM) and enhanced decoding of low-contrast or damaged barcodes, the HF811 ensures reliable performance across challenging surfaces, including metal and plastic. The red LED lighting offers consistent barcode visibility in well-lit industrial environments where specific material reflectivity can hinder white light performance.
Optimised for seamless deployment, the HF811 includes DataMax Plus configuration software and Autotune, enabling one-button optimisation of scan parameters. It connects easily via RS232, RS485, TCP/IP, Profinet, Ethernet/IP, and Modbus TCP, ensuring smooth integration with a variety of industrial automation systems.
Product Features
- 2MP High-Resolution Sensor: Captures fine barcodes and complex marks with precision.
- Narrow Field of View (FOV): Designed for focused, high-density scanning applications.
- Red LED Illumination: Ideal for consistent scanning in high-contrast industrial settings.
- Compact Industrial Housing: Small footprint with rugged IP65-rated design for dust and water protection.
- DPM Decoding Capabilities: Perfect for etched, dot-peened, or laser-marked barcodes.
- Liquid Lens Autofocus: Rapid adjustment for variable scanning distances without mechanical wear.
- Flexible Connectivity: Supports RS232, RS485, TCP/IP, Profinet, Ethernet/IP, Modbus TCP.
- Easy Setup: Autotune and DataMax Plus software streamline configuration and deployment.
- Reliable Performance: Designed for 24/7 industrial operations with 3-year warranty support.
- Integration Ready: Compatible with external triggers and lighting accessories.
Product Specifications
Specification | Details |
Imaging Resolution | 2 Megapixel (HF811) |
Scan Pattern | Area Image |
Illumination | Red LED |
Lens Type | Liquid Lens |
Field of View | Narrow (Horizontal: ~20°, Vertical: ~11°) |
Decode Capability | 1D, PDF417, 2D (QR, DataMatrix, Aztec, MaxiCode), DPM |
Interfaces | RS232, RS485, TCP/IP, Profinet, Ethernet/IP, Modbus TCP |
Input Voltage | 240V |
Output Current | 24VDC / 5A |
Operating Temperature | 0°C to 50°C |
Storage Temperature | -20°C to 70°C |
Humidity | 5% to 95% non-condensing |
Ingress Protection | IP65 |
Dimensions (H x W x D) | 70 mm x 55 mm x 45 mm |
Weight | 180g |
Configuration Tools | DataMax Plus, Autotune |
Warranty | 3-Year Factory Warranty |
Features
- Wireless
- Non-rugged
- Fixed Mount
- 2D
- Serial/RS232
- Standard Range
- Red
- General purpose
- Entry Level
- IP65
- Retail
- 3 Years
- New
