Socket Mobile DuraScan D720 Barcode & QR Code Scanner – Gray, Bluetooth 1D/2D, IP54, with Charging Stand

Wireless, Non-rugged, Socket, Handheld, 2D, Bluetooth, Standard Range, Grey, General purpose, Entry Level, IP54, Logistics/Warehouse, 1 Year, New
[Contact us for a price] Request a quote
For Special & Volume Pricing - Call +441749608334
CX4053-3116

Need Help

Choosing a Product
+441749608334 Live Chat Email Us
Talk to our technical Expert
price match

Description

The Socket Mobile DuraScan D720 (Gray) is a highly mobile and rugged barcode reader capable of scanning 1D and QR (2D) codes from printed and digital sources. Built to withstand challenging conditions with its IP54-rated exterior, drop resistance, and replaceable battery, the D720 excels in environments like warehousing, manufacturing, logistics, and field operations.

This compact scanner connects easily via Bluetooth to iOS, Android, Windows, Mac, and Linux devices. It features intuitive feedback via LEDs, audio, and vibration, and supports auto-scan (presentation mode) for hands‑free operation. The gray finish offers a professional aesthetic, and each unit includes a matching charging stand for easy docking and charging. Certified Apple®‑ready and Capture SDK supported for seamless app integration, the DuraScan D720 delivers reliable performance across all platforms.

Product Features

  • Scans both 1D and 2D barcodes (QR, PDF417, Data Matrix, Aztec) on screens or paper
  • Bluetooth wireless connectivity with up to 10 m range
  • iOS certified (Apple® MFi), also compatible with Android, Windows, Mac, Linux
  • IP54-rated housing protects against dust and splashes; drop‑tested up to 2 m
  • Presentation mode (auto-scan) enables hands‑free scanning in docking station
  • Field‑replaceable 1400 mAh rechargeable battery (up to 85,000 scans)
  • Ergonomic, lightweight design with wrist strap included
  • LED, sound, and vibration feedback for scan status and battery alerts
  • Capture SDK available for native application integration
  • Charging stand included in gray finish to match scanner
  • Designed and assembled in the USA with 1‑year warranty


Product Specifications

Specification

Details

Scan Technology

1D/2D Barcode Imager (LED aimer)

Sensor Resolution

1280 × 960 pixels

Scan Angle (H × V)

44.5° × 33.5°

Print Contrast

Minimum 25>#/span###

Bluetooth Version

v2.1 + EDR, Class 2 (up to 10 m range)

Bluetooth Profiles

HID, SPP, iOS App Mode

Charge Time

~6 hours

Battery Weight

35 g (Lithium content: 9.32 g)

Drop Resistance

Survives six 2 m drops to concrete

Tumble Test

2,500 cycles from 1 m drop

Ingress Protection

IP54 (dust & water splash resistant)

Operating Temperature

0 °C to 45 °C

Storage Temperature

-5 °C to 70 °C

Weight

Lightweight portable design

Colour

Gray (scanner & charging stand)

Warranty

1 Year

Features

Connectivity:
  • Wireless
Ruggedness:
  • Non-rugged
Brand:
Socket
Form Factor:
  • Handheld
Scan Engine/Technology:
  • 2D
Interface:
  • Bluetooth
Scan Range:
  • Standard Range
Colour:
  • Grey
Rugged:
  • General purpose
Usage:
  • Entry Level
IP Rating:
  • IP54
Industry/Vertical:
  • Logistics/Warehouse
Warranty:
  • 1 Year
Product Type/Condition:
  • New

Attachments

Brochure (4523-datasheet.pdf, 1,243 Kb) [Download]
