Description
The TSC TC310 300 dpi Desktop Barcode Printer is a high-performance thermal transfer and direct thermal printer designed for professional label printing applications. With a 300 dpi resolution, USB, RS232, and Ethernet connectivity, and a compact, durable double-walled clamshell design, this printer is ideal for businesses requiring precise and high-quality barcode and label printing. It supports multiple programming languages, including TSPL-EZ™, making it compatible with a wide range of software applications. The 2.3" color TFT display ensures easy operation, while expandable memory up to 32 GB enhances functionality.
Product Features
High-Resolution Printing – 300 dpi resolution for sharp, clear labels
Thermal Transfer & Direct Thermal Printing – Versatile printing options
Compact & Durable – Space-saving clamshell design with robust build
User-Friendly Interface – 2.3” color TFT display for easy navigation
Fast & Efficient – Prints up to 102 mm (4”)/second
Multiple Connectivity Options – USB 2.0, RS232, and Ethernet for seamless integration
Large Memory Capacity – 128 MB Flash, 64 MB SDRAM, expandable up to 32 GB
Energy Efficient – ENERGY STAR® qualified for reduced power consumption
Versatile Media Handling – Supports multiple label types including die-cut, black mark, and fan-fold
Advanced Sensors – Includes gap transmissive, black mark reflective, and ribbon end sensors
Product Specifications
| Printing Method | Thermal Transfer & Direct Thermal |
| Resolution | 12 dots/mm (300 dpi) |
| Max. Print Speed | 102 mm (4”)/second |
| Max. Print Width | 105.6 mm (4.15”) |
| Max. Print Length | 11,430 mm (450”) |
| Enclosure | Double-walled plastic |
| Physical Dimensions | 203 mm (W) × 191.5 mm (H) × 259.3 mm (D) |
| Weight | 2.3 kg (5.07 lbs) |
| Label Roll Capacity | 127 mm (5”) OD |
| Ribbon Capacity | 110 m long, max. OD 40 mm, 0.5” core (ink coated outside) |
| Processor | 32-bit RISC CPU |
| Memory | 128 MB Flash, 64 MB SDRAM, SD card slot (expandable up to 32 GB) |
| Interface Options | USB 2.0, RS232, Ethernet, USB Host |
| Display | 2.3” color TFT display, 320 x 240 pixels |
| Power Supply | AC 100-240V, DC 24V 3.75A, 90W |
| Sensors | Gap transmissive, black mark reflective (adjustable), head open, ribbon end |
| Barcode Support | 1D & 2D barcodes including Code 39, Code 128, QR Code, PDF417, GS1 DataMatrix, etc. |
| Printer Language | TSPL-EZ™ (Compatible with EPL, ZPL, ZPL II) |
| Media Types | Continuous, die-cut, black mark, fan-fold, notch |
| Media Width | 20 ~ 112 mm (0.79” ~ 4.4“) |
| Media Thickness | 0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) |
| Operating Temperature | 5 ~ 40°C, 25~85% non-condensing |
| Storage Temperature | -40 ~ 60°C, 10~90% non-condensing |
| Certifications | FCC Class B, CE Class B, UL, ENERGY STAR®, RoHS, WEEE |
