Description
The Zebra DS5502-SR Fixed Mount Scanner Kit delivers high-performance 1D/2D barcode scanning in a compact form factor, ideal for retail, manufacturing, and kiosk applications. Designed for tight spaces, this fixed-mount scanner offers hands-free, omnidirectional scanning of printed and electronic barcodes with unmatched speed and accuracy. Whether you’re embedding it into a self-service solution or mounting it in a production environment, the DS5502-SR ensures fast, reliable data capture every time.
This kit includes the DS5502-SR40004ZZWW scanner and a 7-foot USB cable (CBL-U10755-01), ready to integrate seamlessly into your point-of-sale, ticketing system, or automation solution.
Product Features
- High-Performance 1D/2D Scanning: Captures printed and digital barcodes instantly, even if damaged or low contrast.
- Ultra-Compact Design: Small enough to fit in tight spaces, perfect for kiosks, counters, and embedded use.
- Omnidirectional Scanning: No need to align barcodes — scan from any angle.
- Rugged and Durable: Built to endure 5 ft (1.5 m) drops and sealed to IP54 for protection against dust and water.
- Easy Mounting: Compatible with standard camera mounts and Zebra’s 3-in-1 mount system.
- LEDs and Audible Feedback: Ensures accurate scans in loud or poorly lit environments.
- Wide Barcode Support: Reads 1D, 2D, PDF417, DataMatrix, QR Codes, and more.
- Plug-and-Play USB Connectivity: Includes 7 ft USB cable for instant setup and ease of integration.
- Supports Mobile Barcodes: Reads barcodes off smartphones, ideal for digital tickets and loyalty cards.
- Optional Driver’s License Parsing: Enables automated data capture for age verification and ID processing (region-dependent).
Product Specifications
| Specification | Details |
| Scanner Model | Zebra DS5502-SR40004ZZWW |
| Included Cable | CBL-U10755-01 – 7 ft USB cable |
| Scan Engine | 1280 x 800 pixel area imager |
| Scan Range (13 mil UPC) | 1.0 in to 18.3 in (2.5 cm to 46.5 cm) |
| Scan Angles | Pitch: ±60°; Roll: 360°; Skew: ±60° |
| Weight | 3.0 oz (85 g) |
| Sealing | IP54 |
| Drop Spec | 5 ft (1.5 m) to concrete |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5% to 85% non-condensing |
| Light Immunity | 0 to 10,000 foot candles (0 to 107,600 lux) |
| Connectivity | USB (via included cable) |
| Warranty | 3 years |
Features
Connectivity:
- Wired
Ruggedness:
- Non-rugged
Brand:
Zebra
Form Factor:
- Fixed Mount
Scan Engine/Technology:
- 2D
Interface:
- USB
Scan Range:
- Standard Range
Colour:
- Black
Rugged:
- General purpose
Usage:
- Entry Level
IP Rating:
- IP54
Industry/Vertical:
- Logistics/Warehouse
Warranty:
- 3 Years
Product Type/Condition:
- New
